What is the Proper Battery Cable Connection When Jumping Two Automotive Batteries?

March 15, 2024 | Victor Lukasso

You need to follow the instructions if you want to use jumper cables in jump-starting your car with the help of another vehicle:

You need to identify where each car’s battery is. In some vehicles, the battery is with the engine. Now you need to park the cars close together so that you’ll be able to connect jumper cables to the cars’ batteries. Now you need to be careful that no parts of either car touch the other.

It is essential to prevent the flow of electrical current between the vehicles other than through the jumper cables. Both cars must be powered off in the park before you begin the process. You should know whether each battery’s terminal is positive or negative.

Before you attach the jumper cables to the appropriate places, the positive (red) cable has to be connected to the positive terminals on each battery. Likewise, the negative (black) line needs to have one end attached to the dead battery’s negative terminal and one end grounded.


The most effective and safest order to attach the jumper cables is as follows:

  1. You must attach one red jumper cable clamp to the positive terminal on the dead battery.
  2. Then, attach the other end of the same cable so that the second red jumper cable clamp to the positive terminal on the working (live) car battery.
  3. Likewise, you must attach one black jumper cable clamp to the negative terminal of the working (live) car’s battery.
  4. To complete the process, attach the other end of that cable, the second black jumper cable clamp, to an unpainted piece of stationary metal on the car with the dead battery. Make sure you don’t attach this clamp to the negative terminal on the dead car’s battery.
Recommended:  Car Died While Driving? Do this

You can Purchase Jumper Cables on Amazon for as cheap as $14 – $50.

Components of a Battery

The main elements of batteries used in automobile engine batteries are as follows.

1. Container – The steel can portion of an automotive battery is used to enclose the components of the cell to create the cathode, which is the electrochemical reaction.

2. Cathode – a car battery that includes a cathode and manganese dioxide. The electrochemical process reduces the electrode.

3. Separators – An automobile battery is made with a nonwoven, fibrous fabric to keep the electrodes apart.

4. Anode – a Zinc metal was driven by anodes, which are electrodes that oxidize.

5. Electrolyte – An automated battery with electrolytes is the conduit for ions’ movement within the cell. It transports the battery’s internal ionic current. It is created from potassium hydroxide and water solution.

Recommended:  Automotive Batteries are an Example of Which Hazard Class?

6. Collector – a brass pin connecting the cell to the external circuit for electricity transmission.

Functions Of An Automotive Battery

Many drivers might not be aware of the automobile battery’s primary functions in a vehicle. Many of your car’s most crucial functions are stored in a battery.

These are a few of the primary roles that an automobile battery plays.

1. Starter for the Engine

When you turn the key or press the engine start button, the chemical energy in your battery is converted to electrical energy, which is then automatically distributed to all the sections that may require it. This is one of the main functions of a car battery.

2. Voltage Regulator

Old automobile batteries generate high voltage spikes that would typically cause significant damage to your car. Fortunately, a car battery can take in excess power that other components could produce. Damage from abnormal voltage levels is prevented from happening to solid elements and the entire electrical system.

3. Sustainer

A correctly functioning battery ensures the long-term durability of your car’s powertrain. When you start your car’s engine, an alternator recharges the battery to continue powering everything while driving. In addition, it will be able to begin storing chemical energy once more, providing enough to turn the car’s engine on the next time.

Recommended:  Automotive Battery: Characteristic, Components, Functionality Specifications, and Maintenance

4. An ignition system assistant

The battery kickstarts the ignition system when you start your car’s engine. Your car’s battery connects to the system that powers everything and activates the safety measures. You will be able to determine whether the energy system is malfunctioning immediately. All electronic equipment is powered by a battery when the engine is not running.

5. Alternator

Your car’s battery sends electricity to the alternator, which, in an ideal situation, powers electric features like air conditioning, wipers, headlights, and an airbag system. It’s intended to keep the car running. Thus, if an alternator malfunctions, a battery will start as a backup and keep you going for some time.

That’s all you need to know about the proper battery cable connection when jumping two automotive batteries.
